آلة تفريز - عمودية ACIERA 23 STAE

TECHNICAL SPECIFICATION
  longitudinal travel: 500 mm
  cross travel: 300 mm
  vertical travel: 460 mm
  drilling capacity full bore (steel): 23 mm
  Spindle         &nb: 120 mm
  Spindle speed    from: 45 /min
  .. to: 4000 /min
  Advance         &nb: 0.02 mm/r
  .. to: 0.6 mm/r
  table surface (left-right): 760 mm
  table surface (front-back): 400 mm

ELECTRICAL SPECIFICATIONS
  mains voltage: 400 V
  mains frequency: 50 Hz

DIMENSIONS / WEIGHTS
  space requirements -left/right-: 1300 mm
  space requirements -front/back-: 1300 mm
  total height: 2200 mm
  total weight approx.: 1400 kg
