Machine type: | Surface Grinding Machine |
Manufacturer: | BLOHM |
Year of manifacturing: | 1999 |
Type: | Planomat 408 CNC |
Condition: | used |
Attended time: | h |
Number of reference: | p217903 |
Make | BLOHM |
Type of machine | Planomat 408 CNC |
Year of manufacture | 1999 |
Control system | Siemens 810 |
Table area | 800 x 400 mm |
max. Table load | 800 kg |
Max. grinding length | 800 mm |
Grinding wheel size | 400 x 80 x 127 mm |
Max. grinding width | 400 mm |
Max. workpiece height | 0 mm |
Max. distance between the table and the center of spindle | 150 - 700 mm |
Control | CNC |
Machine's weight | 3,9 t |
Overall dimensions | 4.250 x 3.400 x 2.800 mm |
Power consumption | kVA |
Spindle drive | 7,5 kW |
Longitudinal travel | 900 mm |
Grinding spindle speed range (stepless) | 1650 U/min |
Vertical travel | 550 mm |
Delivery period | kurzfristig-nach Vereinbarung |
Cross traverse | 360 mm |
Price | Auf Anfrage |
