| Machine type: | CNC Turning and Milling Machine |
| Manufacturer: | DOOSAN DAEWOO |
| Year of manifacturing: | 2012 |
| Type: | PUMA TT 1500 Y |
| Condition: | used |
| Attended time: | h |
| Number of reference: | p190695 |
| Make | DOOSAN DAEWOO |
| Type of machine | PUMA TT 1500 Y |
| Year of manufacture | 2012 |
| Control system | FANUC 18 iTB |
| spindle motor | 15 kW |
| Diameter of spindle bore | 65 mm |
| Rapid longitudinal/cross feed | 24 m/min |
| Total power requirement | ca 40 kVA |
| Cutting diameter | 500 mm |
| Control | CNC |
| Machine's weight | 5.500 kg |
| Turning length | 200 mm |
| Overall dimensions | 3.5 x 1.8 x 2 m |
| Traverse X-axis | 165 mm |
| Traverse Z-axis | 470 mm |
| Rapid Y - axis | 16 m/min |
| Traverse Y-axis | 100 +/-50 mm |
| Power-driven tool holding fixture |  |
| C-axis | 20 min-¹ |
| Bar feeder | IEMCA ADVNTAGE 66 MM LENG 1500 MM |
| Milling spindle motor | 5.5 kW |
| Number of tool slots under revolver | 12 |
| Number of tool slots / of which the number of power-driven tool slots is | 2 X 12 |
| Delivery period | nach Vereinbarung |
| Price | Auf Anfrage |
