CONTROLS
CNC controls SIEMENS 840 D
BASIC FUNCTIONS
number of spindles: 1
number of turrets: 1
live positions: yes
WORKING RANGE TURNING
swing diameter (max): 520 mm
turning diameter (max): 500 mm
worpiece length max.: 200 mm
MAIN SPINDLE
spindle revolutions (max): 3400 /min
drive power: 71 kW
spindle torque: 750 Nm
X/Z SLIDE
X-axis travel: 1000 mm
rapid traverse Z: 30000 mm/min
rapid traverse X: 45000 mm/min
tool fixture: Turret
number of tool positions (total): 12
- rotation speeds (max): 6000 /min
ELECTRICAL SPECIFICATIONS
mains voltage: 400 V
mains frequency: 50 Hz
DIMENSIONS / WEIGHTS
space requirements -left/right-: 3950 mm
space requirements -front/back-: 1570 mm
total height: 3200 mm
total weight approx.: 13500 kg
ATTACHMENTS (TURNING)
chip conveyor: yes
coolant unit: yes
-Tools according to DIN 69880
-Pre-equipped for workpiece measurement
-Accessories : approx. 55 fixed + driven tools
Sold
