| Machine type: | Injection molding machine - clamping force 1000 - 4999 kN |
| Manufacturer: | ENGEL |
| Year of manifacturing: | 2004 |
| Type: | VICTORY 750-180 Power |
| Condition: | used |
| Attended time: | h |
| Number of reference: | p160793 |
| Make | ENGEL |
| Type of machine | VICTORY 750-180 Power |
| Year of manufacture | 2004 |
| Control system | CC100 |
| Machine's weight | 12900 kg |
| Mould seating thrust | 1800 kN |
| Max. daylight opening | 1050 mm |
| Injection pressure | 1910 bar |
| Installation height | 300 mm |
| Grinding screw diameter | 50 mm |
| Overall dimensions | 6.45m x 1.8m x 2.2m |
| Support plate size | 850 x 820 mm |
| Flange opening width | 750 mm |
| Displacement volume | 392 mm |
