| Machine type: | CNC Turning Machine |
| Manufacturer: | HURCO |
| Year of manifacturing: | 2014 |
| Type: | TMX 8 MYS |
| Condition: | used |
| Attended time: | h |
| Number of reference: | p225756 |
| Make | HURCO |
| Type of machine | TMX 8 MYS |
| Year of manufacture | 2014 |
| Control system | : Hurco Ultimax. Mit viel Zubehör. |
| Input power | 30 KVA |
| Control | CNC |
| Machine's weight | 5,6 t |
| Turning length | 724,5 mm |
| Feed | 0-30 m/min |
| Overall dimensions | 4,3 x 2,1 x 2,6 m |
| Swing over saddle | 336 mm |
| Longitudinal travel | 580/640 mm |
| Machining diameter over bed | 0508 mm |
| Slide travel | 203,2 mm |
| Main motor | 15/22 kW |
| Spindle turning speed - stepless | 0- 4500 U/min- rpm |
| Operating voltage | 400 V |
| Counter spindle | , Kraftspannfutter, Kühlmitteleinrichtung und Späneförderer. |
| X and Z rapid feed | 30 m/min |
| Tool drive power | 5,5 kW |
| Tool speed range | 0- 5000 U/min |
| C-axis | 360 x 0,001 ° |
| Spindle opening | 65 mm |
| Delivery period | nach Absprache |
| Price | Auf Anfrage |
