| Machine type: | CNC Turning and Milling Machine |
| Manufacturer: | MORI SEIKI |
| Year of manifacturing: | 2006 |
| Type: | NL1500SY/500 |
| Condition: | used |
| Attended time: | h |
| Number of reference: | p221371 |
| Make | MORI SEIKI |
| Type of machine | NL1500SY/500 |
| Year of manufacture | 2006 |
| Control system | MSX-850 |
| Swing over bed | 500 mm |
| Total power requirement | 36 kVA |
| Cutting diameter | 490 mm |
| Control | CNC |
| Machine's weight | 5 t |
| Shank diameter | 50 / 32 mm |
| Turning length | 515 mm |
| C-axis | 0,001 ° |
| Chip removal device |  |
| Overall dimensions | 3,5 x 2,0 x 2,1 m |
| Traverse X-axis | 280 mm |
| Traverse Z-axis | 490 mm |
| Spindle drive power | 18.5 kW |
| Bar diameter | 52 mm |
| Bar cross-section | 25 x 25 mm |
| X and Z rapid feed | 30 m/min |
| Power-driven too speed range | 6000 min-1 |
| Speed range – spindle 1 | 6000 min-1 |
| Spindle bearing diameter | 110/75 mm |
| Number of tools in revolver 1 | 12 |
| Spindle lock 1 | A2-6 |
| Turret change-over time | 0,25 s |
| Rapid feed C - axis | 400 min -1 |
| Piece counter | |
| Signaling light | 3 farbig / 3 colors |
| Parts trap | |
| Power-driven tool power | 5,5 kW |
| Delivery period | sofort |
| Price | Auf Anfrage |
