| Machine type: | Gear grinding machines butts |
| Manufacturer: | PFAUTER-KAPP |
| Year of manifacturing: | 1994 |
| Type: | PE 1600 G |
| Condition: | used |
| Attended time: | h |
| Number of reference: | p226202 |
| Make | PFAUTER-KAPP |
| Type of machine | PE 1600 G |
| Year of manufacture | 1994 |
| Control system | Sinumerik 840 C |
| max. Table load | 15 t |
| Total power requirement | 80 kVA |
| Control | CNC |
| Wheel width | - mm |
| Machine's weight | 17 t |
| Overall dimensions | 7,7 x 6,9 x 3,9 m |
| Feed speed | X: 3.000 mm/min |
| Table diameter | 1.200 mm |
| Opening in the work table | 300 mm |
| Grinding wheel diameter | 400 mm |
| Grinding wheel width | 80 |
| Delivery period | nach Vereinbarung |
| Radial slide travel | 1.000 mm |
| Tangential adjustment | 300 mm |
| Price | Auf Anfrage |
| 80 mm |
