| Machine type: | Machining Center - Universal |
| Manufacturer: | QUASER (5-ACHSEN) |
| Year of manifacturing: | 2002 |
| Type: | MV204IIU / 10 |
| Condition: | used |
| Attended time: | 13.975 h h |
| Number of reference: | p234096 |
| Make | QUASER (5-ACHSEN) |
| Type of machine | MV204IIU / 10 |
| Year of manufacture | 2002 |
| Control system | HEIDENHAIN ITNC 530 |
| spindle motor | 15/33 kW |
| spindel speed | 10.000 U/min/rpm |
| x-travel | 700 mm |
| y-travel | 590 mm |
| z-travel | 480 mm |
| max. Table load | 265 Kg |
| Total power requirement | 30 kva |
| Spindle lock | BT - 40 |
| Control | CNC |
| Machine's weight | 8,2 t |
| Operating time | 13.975 h |
| Overall dimensions | 2.220 X 2.650 X 2.855 m |
| Feed | 15.000 m/min |
| Rapid feed x/y/z | 32.000 mm/min |
| Tool changer assembly | 32 pos. |
| C-axis | 360 ° |
| A-axis | ±110 ° |
| Torque | 192/189 Nm |
| Delivery period | Sofort |
| Price | Auf Anfrage |
