Sold
| Machine type: | Gear grinding machines butts |
| Manufacturer: | REISHAUER |
| Year of manifacturing: | 1989 |
| Type: | RZ 301 S |
| Condition: | used |
| Attended time: | h |
| Number of reference: | p222334 |
| Make | REISHAUER |
| Type of machine | RZ 301 S |
| Year of manufacture | 1989 |
| Input power | 24 kVA |
| Max. workpiece weight | ca. 60 kg |
| Control | CNC |
| Wheel width | 175 mm |
| Clamping length | 420 (750) mm |
| Feed per workpiece revolution | 0,6 - 3 mm/WU |
| Slide feed | 180 mm |
| Grinding spindle speed range | 1100 - 1900 (Schleifen) U/min |
| Grinding wheel diameter | 270 - 350 mm |
| Grinding wheel width | 84 - 104 mm |
| Number of teeth | 10 - 600 |
| - | 45 ° |
| - | 10 mm |
| Required space | 6000 x 6000 x 2300 mm |
| Voltage | 380V / 50Hz |
| Delivery period | sofort |
| Price | Auf Anfrage |
