Токарный станок с ЧПУ GILDEMEISTER CTX 310 V4, г.в. 2006

CONTROLS
  CNC controls SIEMENS 840 D MIT SHOPTURN

BASIC FUNCTIONS
  number of spindles: 1
  number of turrets: 1
  live positions: yes
  number of c-axes: 1
  number of y-axes: 1

WORKING RANGE TURNING
  swing diameter (max): 500 mm
  turning diameter (max): 330 mm
  bar diameter (max): 51 mm

MAIN SPINDLE
  spindle revolutions (min): 20 /min
  spindle revolutions (max): 6000 /min
  drive power S1 100%: 12 kW
  spindle torque S1 100%: 115 Nm
  spindle diameter: 100 mm
  c-axis: yes

X/Z SLIDE
  Z-axis travel: 450 mm
  X-axis travel: 202 mm
  Y-axis travel: 80 mm
  rapid traverse Z: 30000 mm/min
  rapid traverse X: 24000 mm/min
  rapid traverse Y: 10000 mm/min
  tool fixture: Turret

TAILSTOCK
  taper: MK 4
  Z-axis travel: 450 mm

ELECTRICAL SPECIFICATIONS
  mains voltage: 400 V
  mains frequency: 50 Hz

ATTACHMENTS (TURNING)
  chip conveyor: yes


Machine in TOP condition!!
8500 h spindle hours

exklusiv
complete equipment 6000 EUR
